Roadeo Flatbed Range

The Ktwo Roadeo Flatbed trailers come with a high standard specification, suited to the demands of today’s professional farmer and contractor. Available in lengths of 26–44 ft and with a carrying capacity of 14 – 18 tonnes they are sure to withstand the toughest of demands.

Roadeo FB 26

14,000 kg rated carrying capacity

7.95m (26ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Roadeo FB 28

14,000 kg rated carrying capacity

8.55m (28ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Roadeo FB 30

16,000 kg rated carrying capacity

9.15m (30ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Roadeo FB 32

16,000 kg rated carrying capacity

9.75m (32ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Roadeo FB 40

17,000 kg rated carrying capacity

12.19m (40ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Roadeo FB 44

18,000 kg rated carrying capacity

13.41m (44ft) bed length

2.55m (8′ 4″) bed width

Chequer plate floor

Sprung drawbar

10 stud Commercial axles with 420x180mm brakes

100mm wide multi leaf axle spring set

Front & rear bale raves

Standard specifications

Ancillary Equipment

  • LED lighting all round including twin rear light clusters, side markers and flashing beacon
  • Bolt on rear light unit guards
  • Removable drawbar skid with stowage point
  • Mudguards and front/rear spray suppression flaps

Chassis

  • Heavy duty universal beam chassis
  • Option of fixed or sprung drawbar
  • Running gear optimally positioned to aid manouverability

Floor

  • Checker plate floor
  • Rolled steel angle side channel for ease of attaching strap hooks
  • RHS floor bearers spaced every 400mm
  • Rope hooks welded on to floor bearers

Running Gear

  • Commercial 120mm square axles
  • 10 stud 420 x 180 mm brake hubs to achieve 50% braking efficiency
  • Multi leaf sprung axles with 2,000mm track width for maximum stability
  • Ratchet style handbrake

Quality

  • High Specification manufacture in modern factory facilities
  • 3D design package used to ensure consistent product quality
  • Shot blasted paint preparation
  • Finished with 130 microns of two pack acrylic paint
